• Is the fuel flow unit set as L/nm? If so, is the boat speed zero? This unit setting requires speed greater than zero.
  • Are you sure the card is installed? Only the rough base map is displayed without navigation charts.
  • Is your current area covered by the attached chart card? Check the available charts from Settings -> Navigation -> Navigation charts.
    • Is the card factory installed? If not, we currently support only C-MAP 4D cards.
    • Check that the NMEA2000 cables are connected correctly and that the network is terminated at both ends.
    • Check that the Yamaha gateway is installed (only for Yamaha engines).
      • Is other NMEA2000 information shown correctly? Check the available NMEA devices from Settings – System – NMEA information.
      • Is Q connected to the internet either via mobile or wifi? Check for mobile and/or wifi signal strength icon on the top left corner of the display.
      • Does Q have position information (i.e. boat icon visible in the navigator)? The position icon in the sidebar (top left corner of the display) should be white.
        • Does Q have time? Check for clock visibility in the sidepanel (top left corner of the display).
        Whining noise heard from the speakers usually come from ground loop between the Q and the amplifier. Install audio ground loop isolator (audio transformer) in the audio cable from the Q to the amplifier.
        If fuel level shown on the Q is low when the tank is full and vice versa, the fuel sensor type setting is wrong. See Settings – Boat – Fuel sensor. Normally the setting in Buster boats should be A type (US type sensor). The Phantom is an exception. If Yamaha Helm master is installed the fuel information is coming through NMEA2000 and the Qs should be configured to have 2 fuel sensors. One with NMEA2000 instance id 0 and one with id 1.
        • Check the Raymarine CP100 power led. Solid green: Power on (takes < 1 minute); green 1 blink: normal operation; amber 1 blink: transducer disconnected; amber 2 blinks: no ethernet network detected; amber 5 blinks: under voltage 34.2V.
        • Maintenance release, small improvements from feedback.
        • Support for user linking. This feature is boat manufacturer specific and the support for each brand is announced separately. User can be linked currently for Buster’s mobile phone user from Settings > Connectivity > Link mobile phone.
        • Added trips management. A trip is automatically started when the engine starts and ended when starting to shutdown the system. The trips can be viewed from the utility menu in the navigator application. The trips are synchronized with the user’s approval to the Q server (requires successful user linking).
        • Added support for accessing boat information remotely by sending boat information to the Q server. Remote access is boat manufacturer specific and the support for each brand is announced separately.
        • Added support for changing the graphics element size in the marine chart. Access this setting from Settings > Navigation > Graphics size.
        • Extended displayed information shown in the System information.
        • Added QR code to the System information page to allow easier support requests. Read this code with your supporting mobile phone app and a support email with essential information prefilled is created for you.
        • Modifications to weather application to show more detailed forecast for near future.
        • Updated route icons.
        • Improvements to GPS to make the GPS fix acquiring more reliable and faster.
        • Numerous other improvements from feedback.
        • Added support for Raymarine Quantum radar.
        • Added audio equalizer (accessed from Settings -> System -> Audio equalizer).
        • Added support for searching places (see Support page’s Tips and Tricks).
        • Modified weather display to show more detailed short time forecast.
        • Applied fixes for the GPS position problems (slow or no fix).
        • Numerous other optimizations and fixes.
        • New setting: Minimum automatic brightness to determine the lowest value of the automatic brightness adjustment.
        • Improved GPS startup.
        • Stop startup from stopping at the Q logo.
        • Made sidebar customizable (Settings->Display->Sidebar displays or long pressing the sidebar).
        • Sidebar UI modifications: Sidebar width increased a bit, topmost numeric display shown bigger, depth and water temperature displays moved over the seabed display and fuel level made graphical.
        • Updated Wallas Heater application.
        • Show contact information for incoming phone call if paired phone allows access to contacts.
        • Omit startup checks when running in demo mode.
        • A negative trim value is no longer shown as 254.
        • Added support for Telenor SIM cards.
        • Show north as a marker on the boat logo and map when in heading up view.
        • Fixed weather application downloading only one day of weather data.
        • Fixed radio starting to play when Q shuts down because of low voltage.
        • Improved Bluetooth and Q remote support
        • Boat controls application for systems with Q Switch controlling boat peripherals.
        • Slider handle for adjusting numeric settings enlarged for improved modification.
        • OpenSSL upgraded.
        • Linux kernel upgraded to 4.9.41.
        • Added settings option to have chart coloring with more contrast (only two blues and white indicating safe waters).
        • Bars added beside the side panel’s trim value to better indicate the trim status.
        • Ignore too large speed values.
        • Ignore water depth, GPS position and COG SOG from engine (Yamaha gateway).
        • Changed indicator handle (e.g. for alarms) look in the top of the screen.
        • Small translation corrections.
        • Fixed 3G signal strength display
        • Fixed dashboard not showing RPM over 6000
        • Fixed oil pressure display in dashboard
        • Ignore NMEA2000 fuel sensor instances except 0 and 1. Fixes possible jumping heading in Phantom with helmmaster.
        • Ignore invalid NMEA2000 water temperatures
        • Do not indicate engine missing on startup if immobiliser active
        • Fixes for bluetooth streaming problems (upgraded PulseAudio)
        • Extended error log to contain also warning messages and unknown alarms
        • Enhanced boat icon with white border to make it more visible
        • Tuned sensitivity of the chart zoom operations by pinching when the chart position is locked to boat
        • Fixed missing Q startup logo on 16″ devices
        • Fixed bluetooth pairing failure when no name is obtained from the connecting device
        • Improved ethernet connectivity recovery and diagnostics
        • Critical fix for Raymarine sonar which caused sonar data failures.
        • Miscellaneous fixes and improvements to Raymarine sonar. Coloring of the both modes improved.
        • Fixes for multidisplay support.
        • Added more detailed data view to dashboard.
        • Translations updated.
        • Remote controlling improved and verified.
        • Added support for route edition and new route creation.
        • Added support for dynamic boat lock position optimization setting.
        • Added support for two gasoline tanks.
        • Radio application hidden when audio package not installed.
        • Increased maximum zoom range of the navigation charts.
        • 68 other fixes for previously published release.
        • Added support for Raymarine CP100 sonar
        • Added support for Q Remote
        • Added multifunction controller in lower left screen
        • Added support for trolling speed control via cable
        • Moved boat specific settings from Settings->System to Settings->Boat
        • Added “Extra packages” selection in boat. The possible packages are:
          * audio – Amplifier is installed
          * trollingcable – Trolling speed control cable is installed
        • Added details screen to dashboard
        • Added Russian language
        • Added basic support for multiunit setup (more than one Q in a boat)
        • Show correct part of buster owners manual according to language
        • DAB radio fixes
        • New position marker for navigation
        • Faster zooming and panning in navigation
        • Do not start radio automatically when starting Q
        • Fixes and improvements
